M10 MBB PERC 132 half cells 500W-515W solar module
Ultra-high Power Generation/Ultra-high Efficiency
Enhanced Reliability
Lower LID / LETID
High Compatibility
Optimized Temperature Coefficient
Lower Operating Temperature
Optimized Degradation
Outstanding Low Light Performance
Exceptional PID Resistance
| Cell | Mono 182*91mm |
| No. of cells | 132(6×22)/td> |
| Rated Maximum Power(Pmax) | 500W-515W |
| Maximum Efficiency | 21.1%-21.7% |
| Junction Box | IP68,3 diodes |
| Maximum System Voltage | 1000V/1500V DC |
| Operating Temperature | -40℃～+85℃ |
| Connectors | MC4 |
| Dimension | 2094*1134*35mm |
| No.of one 20GP container | 280PCS |
| No.of one 40HQ container | 682PCS |
12-year warranty for materials and processing;
30-year warranty for extra linear power output.
* Advanced automated production lines and first-class brand raw material suppliers ensure that solar panels are more reliable.
* All series of solar panels have passed TUV, CE, CQC, ISO,UNI9177- Fire Class 1 quality certification.
* Advanced Half-cells, MBB and PERC solar cell technology, higher solar panel efficiency and economic benefits.
* Grade A quality, more favorable price, 30 years longer service life.
Widely used in residential PV system, commercial & industrial PV system, utility-scale PV system, solar energy storage system, solar water pump, home solar system, solar monitoring, solar street lights, etc.
MBB PERC cells, or Metal Insulator Back Contact Passivated Emitter and Back Contact cells, are a type of solar cell technology that can be used in solar panels. M10 refers to the specific size of the MBB PERC battery, measuring approximately 182mm x 182mm. The M10 cells are larger than previous generations of MBB PERC cells, typically measuring approximately 156mm x 156mm. The larger size of the M10 cells allows for greater energy output and higher efficiency in solar panel manufacturing.
M10 solar panels have grown in popularity in recent years due to their advanced technology and increased efficiency. They are commonly used in residential and commercial settings to provide clean and renewable energy to homes, businesses and even entire communities. M10 solar panels can be used in ground mount, rooftop or even floating solar systems. They are also commonly used in large solar farms that can generate electricity for entire cities or even countries.
One of the main advantages of the M10 solar panels is that they are able to generate more electricity per square meter than previous generations of solar panels. This is due to their larger size and advanced technology, which allows them to absorb more sunlight and convert it into electricity. As a result, the M10 solar panels are very efficient and can generate a lot of energy even in areas with little sunlight.
Overall, the M10 solar panel is a highly advanced and efficient solar technology that can provide clean and renewable energy for a wide range of applications. They offer many advantages over traditional fossil fuels, including reduced carbon emissions, lower costs and increased energy security.
