G12 MBB,N-Tpye TopCon 132 half cells 670W-700W solar module
Ultra-high Power Generation/Ultra-high Efficiency
Enhanced Reliability
Lower LID / LETID
High Compatibility
Optimized Temperature Coefficient
Lower Operating Temperature
Optimized Degradation
Outstanding Low Light Performance
Exceptional PID Resistance
| Cell | Mono 210*105mm |
| No. of cells | 132(6×22) |
| Rated Maximum Power(Pmax) | 670W-700W |
| Maximum Efficiency | 21.5%-22.4% |
| Junction Box | IP68,3 diodes |
| Maximum System Voltage | 1000V/1500V DC |
| Operating Temperature | -40℃～+85℃ |
| Connectors | MC4 |
| Dimension | 2400*1303*35mm |
| No.of one 20GP container | /// |
| No.of one 40HQ container | 558PCS |
12-year warranty for materials and processing;
30-year warranty for extra linear power output.
* Advanced automated production lines and first-class brand raw material suppliers ensure that solar panels are more reliable.
* All series of solar panels have passed TUV, CE, CQC, ISO,UNI9177- Fire Class 1 quality certification.
* Advanced Half-cells, MBB and PERC solar cell technology, higher solar panel efficiency and economic benefits.
* Grade A quality, more favorable price, 30 years longer service life.
Widely used in residential PV system, commercial & industrial PV system, utility-scale PV system, solar energy storage system, solar water pump, home solar system, solar monitoring, solar street lights, etc.
The G12 MBB, N-Type TopCon 132 half cells 670W-700W solar module is a high-efficiency solar panel that uses advanced technology to generate electricity from sunlight. Here's a breakdown of some of its key features:
• G12 MBB: This refers to the module's use of a "multi-busbar" (MBB) design, which is a technique for optimizing the flow of electrical current through the solar cells. MBB designs typically result in higher efficiency and better performance in hot weather conditions.
• N-Type TopCon: "N-Type" refers to the type of silicon used in the solar cells, which is generally considered to be more efficient than the more common "P-Type" silicon. "TopCon" stands for "Top Contact," which is a design that places the contacts for the solar cells on the top layer of the module, allowing for more efficient electrical connections.
• 132 half cells: This refers to the number and arrangement of the individual solar cells that make up the module. The cells are "half" cells, meaning they are smaller and have a higher voltage than full cells. More cells generally means more power output, but can also increase the cost and complexity of the module.
• 670W-700W: This is the range of power output that the module is rated for under standard test conditions (STC). The actual power output will depend on a variety of factors, including the amount of sunlight the panel receives, the temperature, and the angle and orientation of the panel.
Overall, the G12 MBB, N-Type TopCon 132 half cells 670W-700W solar module is a high-performance solar panel that uses advanced technology to generate electricity efficiently and reliably.
